Maven is the preferred solution for creating Consulo plugins. The maven-consulo-plugin handles dependencies, code generation, and packaging.

WARNING

When adding additional repositories to your Maven build script, always use HTTPS protocol.

Creating a Maven-Based Consulo Plugin

The recommended way to start a new Consulo plugin project is to use the Consulo Simple Plugin Template as a starting point.

Alternatively, you can create a new Maven project manually with the following structure:

Standard Maven Project Structure

my_plugin/
├── pom.xml
└── src/
    ├── main/
    │   ├── java/
    │   └── resources/
    │       ├── META-INF/
    │       │   └── plugin.xml
    │       ├── ICON-LIB/
    │       └── LOCALIZE-LIB/
    └── test/
        └── java/

• The pom.xml file contains the Maven project configuration including the maven-consulo-plugin setup.
• The META-INF directory under the default main source directory contains the plugin configuration file.
• The ICON-LIB directory contains icon definitions that are processed by the generate-icon goal.
• The LOCALIZE-LIB directory contains localization files that are processed by the generate-localize goal.

Example pom.xml

The following pom.xml shows a typical Consulo plugin project configuration:

<project>
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.your.company</groupId>
    <artifactId>my_plugin</artifactId>
    <version>1.0-SNAPSHOT</version>
    <packaging>consulo-plugin</packaging>

    <build>
        <plugins>
            <plugin>
                <groupId>consulo.maven</groupId>
                <artifactId>maven-consulo-plugin</artifactId>
                <extensions>true</extensions>
                <executions>
                    <execution>
                        <phase>generate-sources</phase>
                        <goals>
                            <goal>generate-icon</goal>
                            <goal>generate-localize</goal>
                        </goals>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>

    <repositories>
        <repository>
            <id>consulo-snapshots</id>
            <url>https://maven.consulo.dev/repository/snapshots/</url>
        </repository>
    </repositories>

    <dependencies>
        <!-- Consulo API dependencies -->
    </dependencies>
</project>

Plugin Maven Properties and Plugin Configuration File Elements

The Maven properties project.groupId and project.artifactId will not, in general, match the respective plugin configuration file plugin.xml elements <name> and <id>. There is no Consulo-related reason they should as they serve different functions.

The <name> element (used as the plugin's display name) is often the same as the artifactId, but it can be more explanatory.

The <id> value must be a unique identifier over all plugins, typically a concatenation of the specified groupId and artifactId. Please note that it is impossible to change the <id> of a published plugin without losing automatic updates for existing installations.

Adding Maven Support to an Existing DevKit-Based Consulo Plugin

Converting a DevKit-based plugin project to a Maven-based plugin project:

• Ensure the directory containing the DevKit-based Consulo plugin project can be fully recovered if necessary.
• Delete all the artifacts of the DevKit-based project:
  • .idea directory
  • [modulename].iml file
  • out directory
• Arrange the existing source files within the project directory in the standard Maven source directory layout.
• Create a pom.xml file as shown in the example above.
• Set the values to:
  • groupId to the existing package in the initial source set.
  • artifactId to the name of the existing plugin.
  • version to the same as the existing plugin.
• Import the Maven project in Consulo.

Running a Simple Maven-Based Consulo Plugin

Adding Code to the Project

Before running your plugin, some code can be added to provide simple functionality. See the Creating Actions tutorial for step-by-step instructions for adding a menu action.

Executing the Plugin

Use the Maven package goal to build your plugin:

mvn package

The resulting plugin artifact will be located in the target/ directory and can be installed into Consulo for testing.
